1/2" Composite Impact Wrench, Twin Hammer

1/2" Composite Impact Wrench, Twin Hammer
Model #1000-2-TH Gray/Brush Finish Clutch 2" Anvil Parts List - Aircat

View the Parts Diagram (PDF)

Ref. # Part Number Part Description Qty / Tool Price
1 305Q-002B Hammer Case 1 $24.84
2 00-4302 Inserts Recoil 4 $1.63
3 SC100-03 Grease Fitting 1 $1.08
4 SC100-04 Anvil Bushing 1 $4.68
5 305P-020-B Front Gasket 1 $1.08
6 SC800-07 Anvil Collar 1 $0.98
7 SC800-08 O-Ring 1 $0.98
8 SC100-06 Anvil 1 $30.24
8 SC100-06-2 2" Anvil 1 $38.52
9 SC800-10 Hammer Pin 2 $1.80
10 SC800-11 Hammer 2 $14.40
11 SC800-12 Hammer Cage 1 $30.24
12 SC800-13 Rear Washer 1 $2.16
13 SC800-15 Ball Bearing 1 $5.40
14 305F-005 Front End Plate 1 $11.16
15 305H-007N Rotor 1 $17.28
16 305H-008D Rotor Blade 6 N/A
17 305H-006C Cylinder 1 $73.08
17 SC100-10 Valve Sleeve Gasket 1 $0.98
17 305H-029C Valve Sleeve   1 N/A
17 SC800-24 Ball Bearing 1 $6.05
21 305P-022 Regulator Knob 1 $3.60
22 305Q-021C Regulator 1 $8.64
23 305F-034 Spring 1 $0.98
24 SC100-15 Steel Ball 1 $0.98
25 SC100-16 O-Ring 1 $0.98
26 SC100-17 Rear Gasket 1 $0.98
27 SC100-18 Washer 1 $1.44
28 SC100-19 Air Channel Gasket 1 $0.98
29 305Z-001 Motor Housing 1 $50.04
30 305M-028 Screw 4 $1.08
31 SC100-22 Trigger 1 $2.16
32 SC100-23 O-Ring 1 $0.98
33 SC100-24 Spring Pin 1 $0.98
34 SC800-19 Spring Pin 1 $0.98
35 SC200-30 Bushing 1 $1.70
36 SC200-31 Valve Stem 1 $1.44
37 305F-026-B Spring 1 $0.98
38 SC100-26 Exhaust Deflector 1 $1.44
39 SC100-27 O-Ring 1 $0.98
40 SC100-28 O-Ring 1 $0.98
41 SC100-29 Washer 1 $1.44
42 SC100-30 Air Inlet (1/4" NPT) 1 $8.28
43 305H-019B Muffler 1 $1.08
44 00-1304 Cap Screw 1
N/A
45 305H-019B Exhaust Tube 1 $1.63
46 243H-027 Muffler 1 $0.98
47 SC100-31  O-Ring 1 $0.98
48 305H-041 Square Ring 1 $0.98
